No.	Item	Specification	Unit
1	Panel Size	5.0”	inch
2	Number of Pixels	480×RGB (3)×800	pixels
3	Active Area	108(H)x 64.8(V)	mm
4	Pixel Pitch	45(H) × 3 × 135(V)	um
5	Outline Dimension	120.7(W)×75.8(H)×2.85(D)	mm
6	Number of Colors	16.7M	-
7	Display Mode	Transmission mode, normally black	-
8	Viewing Direction	Full viewing	-
9	Display Format	RGB vertical stripe	-
10	Surface Treatment	Anti-Glare	-
11	Interface	RGB	-
12	Backlight	White LED	-
13	Operation Temperature	-20℃~+70℃	℃
14	Storage Temperature	-30℃~+85℃	℃
15	Weight	-	g
